Hexcel and A&P Technology collaborate with NIAR

“Our collaboration with A&P Technology represents a significant step forward in delivering critical airworthy composite preforms at high rate,” said Lyndon Smith, President, Americas & Global Fibers, Hexcel. “By combining our advanced fibre and resin technology with A&P Technology’s overbraiding expertise, we’re enabling the next generation of high-performance military and commercial aircraft structures.”

A&P Technology, a manufacturer of engineered braided reinforcements, using its line of braiding machinery unmatched in size and complexity, has developed the capability to overbraid large scale aircraft structures at high rate. Development of composite specifications, design data and a methodology for certification acceptable to the Federal Aviation Administration (FAA) will enable the adoption of this high-performance, low-cost, high-rate preform and part manufacturing by commercial airframe builders and will aid in its adoption into military platforms.

Hawthorn Composites (Miamisburg, OH) is currently in production of inlet ducts for the Kratos XQ-58A Valkyrie using this overbraid and resin infused approach. Hawthorn has manufactured full-scale wings and fuselages for the same vehicle using similar approaches under the Design for Manufacture of Attritable Aircraft Primary Structure program (DMAAPS) programme that culminated with a successful full-scale ground vehicle static test conducted by the Air Force Research Laboratory (AFRL). Independent analysis conducted by AFRL concluded that use of braiding and overbraiding techniques on these types of parts would result in 57% cost savings when compared to hand applied prepreg and autoclave cure, and a 67% reduction in touch time.

“Net shape braided preforms and overbraiding are both key technologies enabling the U.S. DoD to realise their vision of affordable mass aircraft solutions,” said Tom Margraf, CEO – Hawthorn Composites.

Overbraiding creates a controlled and predictable fibre change along the length of a part, including those with complex curvatures. Changing angles create mechanical property variation, but the controlled architecture allows for prediction of property change and creation of design envelopes.

The design of a composite combat drone inlet duct produced by NIAR, A&P Technology, and Fiber Dynamics will be used as the basis for the certification development. The complex curvature of the duct represents the types of aircraft structures that will require a path to FAA certification to take advantage of the high rate of manufacture benefits by overbraiding.

A process is now in place that enables production of multiple duct preforms per shift, which opens a path to certification and adoption, according to officials from A&P Technology and NIAR.

“The overbraided serpentine inlet duct we developed under the MASC program is an excellent example of our partners’ capabilities and shows how modern braided composite technologies can advance aerospace innovation,” said Dr. Waruna Seneviratne, director of NIAR’s Advanced Technology Lab for Aerospace Systems (ATLAS). “Together, we are using feedback from specific aerospace primes to create preliminary design values for matrix systems, which will accelerate the process for full qualification and certification.”

“We’re excited to collaborate with Hexcel on this initiative,” said Andy Head, President of A&P Technology. “Our combined technologies offer a compelling solution for OEMs looking to quickly and consistently lay down fibre on complex load paths in complex geometries. This programmewill validate that the resulting structures are as easy to model and certify as incumbent, rate-limiting solutions.”

Cover photo: Hexcel’s booth at JEC World 2025
